Membrane Vacuum Pump MVP-030 24 VDC
$2,861.00
MSRP:
$2,861.00
MSRP:
The MVP-030 is a compact, oil-free diaphragm vacuum pump used on the TITAN VERSA TD helium leak detector. Designed for quiet and efficient operation, this dry pump offers a flow rate of up to 1.8 m³/h while requiring minimal maintenance. Its hydrocarbon-free design makes it ideal for clean applications such as laboratory environments or integration into intelligent vacuum systems via RS-485 interface.
All prices are in US$. Website pricing is good only for the USA. Please call for International pricing.
| Pumping Speed | 1.8 m³/h | 1.06 cfm | 30 l/min |
|---|---|
| Final Pressure | 2 hPa | 1.5 Torr | 2 mbar |
| Final Pressure with Gas Ballast | 3 hPa | 2.25 Torr | 3 mbar |
| Intake Pressure (Max) | 1100 hPa | 825 Torr | 1100 mbar |
| Exhaust Pressure (Max) | 1100 hPa | 825 Torr | 1100 mbar |
| Integral Leak Rate | 1 · 10⁻² Pa·m³/s | < 1.33 Torr·l/s | < 1 mbar·l/s |
| Gas Ballast | Available as an accessory |
| Number of Pumping Stages | Three stage |
| Cooling Method | Natural convection |
| Motor Type | DC motor |
| Nominal Rotation Speed | 1800 rpm | 1800 min⁻¹ |
| Rotation Speed Range | 600–2400 rpm | 600–2400 min⁻¹ |
| Rated Current Consumption | 1.5 A |
| Current (Max) | 7 A |
| Input Voltage(s) | 24 VDC (±10%) |
| I/O Interfaces | RS-485 |
| Mains Cable | No |
| Ambient Temperature Range | 10–40 °C | 50–104 °F | 283.15–313.15 K |
| Operating Altitude (Max) | 2000 m |
| Sound Pressure Level | 45 dB(A) |
| Protection Degree | IP20 Type 1 |
| Connection Flange (In) | G 1/8'' |
| Connection Flange (Out) | G 1/8'' with silencer |
| Dimensions (L x W x H) | 223 x 145 x 217 mm | 8.78 x 5.71 x 8.54 in |
| Weight | 4.3 kg | 9.48 lb |
| Shipping Temperature | -10–60 °C | 14–140 °F | 263.15–333.15 K |
| Storage Temperature | -10–60 °C | 14–140 °F | 263.15–333.15 K |
| Certification | cTUVus (UL / CSA 61010-1) |
